Solar DC Cables Technical Specification

Construction:
• Conductor: tinned copper conductor IEC 60228, Class 5
• Insulation/sheath: electron beam cross linked halogen free & flame retardant compound (XLPO)

Electrical:
• Voltage test: 6500V as per EN 50395.
• Max permissible operating voltage: DC 1.5Kv (conductor-conductor, non earthed system).
• Nominal voltage: AC - 0.6/1 Kv, DC - 900/1.5 Kv.

Temperature:
• Ambient Temperature: -40°C to +90°C.
• Max conductor temperature: 40°C to 120°C.

Max bending radius:
• 5 *OD (fixed installation)
• 15 *OD (occasional moved)

Standards / Material Properties:
• Fire performance: IEC 60332-1-2
• Smoke emission: IEC 61034/ EN 50268-2
• Halogen free: EN 50267-2-1/-2, IEC 60754-2
• Toxicity: EN 50305, ITC - index <3
• Ozone Resistant: EN50396
• Weathering UV: HD 605/A1 or DIN 53367
• Approvals: EN 50618; H1Z2Z2-K
